Unfortunately, existing tools still require that the designer develops large parts by hand, especially when hardware accelerators and partial dynamic reconfiguration are taken into account. The constantly growing complexity of heterogeneous systems requires effective methods for supporting the designer both during the development of the application and the imple mentation of the architecture. The IP reflection and system generation chains were developed using Sodius MDWorkbench, an MDE tool conceived for the creation and manipulation of models and their meta-models, as well as the definition and execution of the associated transformation rules.
Subsequently, these IP templates are used for composing a DPR model that can be exploited to create a Xilinx Platform Studio FPGA-design, through model transformations. This is attained by reflecting the associated IP metadata to IP-XACT descriptions, and then to UML MARTE templates (IP reuse). In fact, a componentizing process enables us to reuse the IP blocks, in UML MARTE, by wrapping them with PLB (static IPs) and proprietary (DPR blocks) interfaces. The proposed methodology has been constructed around the Metadata-based Composition Framework paradigm, and based on common standards such as UML MARTE and the IEEE IP-XACT standard, an XML representation used for storing metadata about the IPs to be reused and of the platforms to be obtained at high-levels of abstraction. The main contribution of this thesis consists on the proposition and development a Model-driven Engineering (MDE) framework, in tandem with a component-based approach, for facilitating the design and implementation of Dynamic Partially Reconfigurable (DPR) Systems-on-Chip.
